Chapter!1!Product!Introduction! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! !
!
1.2!Features!
l Supports!24!10/100/1000Mbps!Gigabit!Ethernet!ports!and!4!mini-GBIC/SFP!slots!
l IEEE!802 .3 a f/ a t!Po E !c o mpliant!to!simplify!de plo yment!and!installation!
l Supports!PoE!up!to!30!W!per!port!with!400!W!total!power!budget!
l Automatically!detects!powered!devices!(PD)!and!power!co ns umption!levels!
l IEEE!802 .1 Q!VLAN!allows!ne twork!segmentatio n !to !e n h an c e !pe rf o rmance!and!secur ity!
l Supports!Access!Control!List!(ACL)!
l Switch!capacity:!56Gbps,!Forwarding!rate:!35.7Mbps!
l Supports!IGM P!S n o o p in g!V 1 !/ !V 2 !
l 8K!MAC!address!table!and!9K!jumbo!frames!
l 19-inch!rack - mountable!metal!case!
!
1.3!External!Component!Description!
1.3.1!Front!Panel! !
The!front!panel!of!the!switch!consists!of!24!x!10/100/1000Mbps!RJ-45!ports,!4!x!SFP!ports!and!a!series!of!LED!
indicators !as !sh o w n !a s!b e lo w :! !
!
!
! Front!Panel!
10/100/1000Mbps!RJ-45!ports!(1~24):!
Connect!to!network!devices!with!a!bandwidth!of!10Mbps,!100Mbps!or!1000Mbps.!
!
SFP!ports!(SFP1,!SFP2,!SFP3,!SFP4):!
Designed!to!install!SFP!modules!and!connect!to!network!devices!with!a!bandwidth!of!1000Mbps.! !
!
! LED !Indicators!
The!following!chart!shows!the!LED!indicators!of!the!Switch!along!with!explanation!of!each!indicator.!
Power:!Green! !
− Off:!Power!off!
− On:!Power!on!
!
