V7 MPEGS24 - 1.4 Package Contents

MANAGED SWITCH
System:!Green!
− Off:!System!not!ready!
− On:!System!ready!
− Blinking:!System!booting!
!
Copper!Port!1G:!Green!
− Off:!No!1G!link!
− On:!1G!link!
!
Copper!Port:!Yellow!
− Off:!100M!link!fail!
− Flashing:!Sending!or!receiving!data!
!
SFP:!Green!
− Off:!Link!fail!
− On:!Connected!
!
SFP:!Yellow!LED!
− Off:!Not!sending!or!receiving!data!
− Flashing:!Sending!or!receiving!data!
1.3.2!Rear!Panel!
The!rear!panel!of!the!switch!feature s!th e !A C !po w e r!c o nn e ct o r:!
!
! Rear!Panel
!
AC!Power!Connector:! !
Power!is!supplied!through!an!external!AC!power!adap ter.!Supports!AC!100!–!240V,!50-60Hz
!
! !
1.4!Package!Contents!
l MPEGS!Switch! !
l Quick!Installation!Guide!
l Power!Cord!
l Rack-Mount!Kit!
!
!
!
!
!
!
!
