V200 POSITIONER
www.vacaccessories.com/v200
V200 External options IOM r210
4.1 Specifications external options
Electropneumatic 0-10V Electropneumatic EX Electropneumatic Fail Freeze
V200 0-10V V200EX V200FF
Input Signal: 0-10VDC (Max:Ri 10K Ohm) 4-20mA (Max:Ri 250 Ohm) 4-20mA (Max:Ri 250 Ohm)
Supply Pressure: <100 PSI (<1MPa) 21.8-100 PSI (0.15-1MPa) 21.8-145 PSI (0.15-1MPa)
Linearity error: <0.8% f.s <0.8% f.s <1.2% f.s
Hysteresis: <0.5% f.s <0.5% f.s <0.9% f.s
Repeatability: <0.4% f.s <0.4% f.s <0.8% f.s
Temperature range: -40° to +160 F -40° to +158 F* -20° to +158 F
-40° to +71C -40° to +70°C* -28° to +70°C
*Temp.range depending on certification
Pressure gain:
@87 PSI (600kPa) 300:1 300:1 300:1
Bleed Rate: SCFM (SLPM) SCFM (SLPM) SCFM (SLPM)
@87PSI (600kPa) 0.38 (11.9) 0.42 (11.9) 0.36 (10.2)
Air Delivery SCFM (SLPM) SCFM (SLPM) SCFM (SLPM)
@87 PSI (600kPa) 28.3 (800) 28.3 (800) 28.3 (800)
Air connections: 1/4” NPT (optional G threads) 1/4” NPT (optional G threads) 1/4” NPT (optional G threads)
Gauges: 1/8” NPT (optional G threads) 1/8” NPT (optional G threads) 1/8” NPT (optional G threads)
Cable entry: 1/2” NPT (optional M20x1.5) 1/2” NPT (optional M20x1.5) 1/2” NPT (optional M20x1.5)
Ingress & corrosion
protection: NEMA 4X and IP66 NEMA 4X and IP66 NEMA 4X and IP66
Standard coating: Polyester Polyester Polyester
Weight: 3.9 lbs (1.76kg) 5.3 lbs (2.40g) 5.4 lbs (2.45kg)
Weight with gauges: 4.3 lbs (1.94kg) 5.7 lbs (2.58kg) 5.8 lbs (2.63kg)
Valve types Normal Gain High Gain Super High Gain
Pressure Gain: @ 29 PSI (0.2MPa) Poutput / Pinput 100 270 370
@ 87 PSI (0.6MPa) Poutput / Pinput 300 800 1100
@ 145 PSI (1.0MPa) Poutput / Pinput 500 1330 1830
Pressure Gain: Any %Poutput / %Pinput 20 52 72
Acc. to ISA S75.13
Air Delivery: @ 29 PSI (0.2MPa) SCFM/(SLPM) 9.4 / (270) 10.6 / (300) 10.6 (300)
@ 87 PSI (0.6MPa) SCFM/(SLPM) 28.3 / (800) 31.8/ (900) 31.8 (900)
@ 145 PSI (1.0MPa) SCFM/(SLPM) 47.1 / (1330) 53.0 / (1500) 53.0 (1500)
Bleed Rate: @ 29 PSI (0.2MPa) SCFM/(SLPM) 0.12 / (3.4) 0.18 / (5.0) 0.24 (6.7)
@ 87 PSI (0.6MPa) SCFM/(SLPM) 0.35 / (10.0) 0.53/ (15.0) 0.71 (20.0)
@ 145 PSI (1.0MPa) SCFM/(SLPM) 0.59 / (16.7) 0.88 / (25.0) 1.18 (33.3)
Options: Feedback Spring for 6-30 PSI (40-200kPa) input signal.
Gauges. Stability kit, feedback modules
