V200 POSITIONER
22
4.1 Specications V200
Pneumatic Electropneumatic Electropneumatic Intrinsically Safe
V200P V200E V200IS
InputSignal: 3-15PSI  4-20mA(Max:Ri250Ohm) 4-20mA(Max:Ri250Ohm)
SupplyPressure: <145PSI (<1MPa) 21.8-145PSI(0.15-1MPa) 21.8-145PSI (0.15-1MPa)
Linearityerror: <0.7%f.s  <1.0%f.s  <1.0%f.s
Hysteresis: <0.4%f.s  <0.6%f.s  <0.6%f.s
Repeatability: <0.3%f.s  <0.5%f.s  <0.5%f.s
Temperaturerange: -40°to+185F -40°to+185F -40°to+185F*
 -40°to+85°C -40°to+85°C -40°to+85°C*
     *Temp.rangedependingoncertication
Valueswithstandardpilotvalve,LB installed.
Pressuregain:
@87PSI(600kPa) 240:1  240:1  240:1
BleedRate: SCFM(SLPM) SCFM (SLPM) SCFM (SLPM)
@87PSI (600kPa) 0.2 (5.6) 0.25 (7.0) 0.25 (7.0)
Air Delivery SCFM (SLPM) SCFM (SLPM) SCFM (SLPM)
@87 PSI (600kPa) 28.3 (800) 28.3 (800) 28.3 (800)
Airconnections: 1/4”NPT(optionalGthreads) 1/4”NPT(optionalGthreads) 1/4”NPT(optionalGthreads)
Gauges: 1/8”NPT(optionalGthreads) 1/8”NPT(optionalGthreads) 1/8”NPT(optionalGthreads)
Cableentry: 1/2”NPT(optionalM20x1.5) 1/2”NPT(optionalM20x1.5) 1/2”NPT(optionalM20x1.5)
Ingress & corrosion
protection: NEMA4XandIP66 NEMA4XandIP66 NEMA4XandIP66
Standardcoating: Polyester  Polyester  Polyester     
Weight: 3.2lbs (1,45kg) 3.8lbs (1.7kg) 3.8lbs (1.7kg)
Weightwithgauges: 3.4lbs (1,54kg) 4.2lbs (1.9kg) 4.2lbs (1.9kg)
Valve types. (SG/LB valve is installed as standard) SG/LB SHG (3) SHGSHF (4)
PressureGain: @29PSI(0.2MPa) Poutput/Pinput  80  367  370
 @87PSI(0.6MPa) Poutput/Pinput  240  1100  1100
 @145PSI(1.0MPa) Poutput/Pinput  400  1833  1830
PressureGain:  Any %Poutput/%Pinput  16  79  72
Acc. to ISA S75.13
AirDelivery: @29PSI(0.2MPa) SCFM/(SLPM) 9.4/(270) 10.5/(297)  16.6/(470)
 @87PSI(0.6MPa) SCFM/(SLPM) 28.3/(800) 31.5/(890)  50.0/(1400)
 @145PSI(1.0MPa) SCFM/(SLPM) 47.1/(1330) 52.5/(1486)  83.4/(2330)
BleedRate: @29PSI(0.2MPa) SCFM/(SLPM) 0.07/(3.4) 0.28/(7.9)  0.4/(12.3)
 @87PSI(0.6MPa) SCFM/(SLPM) 0.2/(5.6) 0.83/(23.5)  1.3/(36.8)
 @145PSI(1.0MPa) SCFM/(SLPM) 0.35/(10.0) 1.38/(39.1)  2.2/(61.3)
Options: FeedbackSpringfor6-30PSI(40-200kPa)inputsignal.Gauges.Stabilitykit,feedbackmodules.
