Page 20 Vacon
Pump and fan control with autochange
Group 10, Fieldbus parameters
Code Parameter Range Step Default Custom Description Page
10.1 Fieldbus control select 0 - 1 1 0 0 = control via I/O terminal 56
1 = control via fieldbus board
10.2 Modbus slave address 1 - 247 1 1 56
10.3 Baud rate 1 - 7 1 6 1 = 300 baud 56
2 = 600 baud
3 = 1200 baud
4 = 2400 baud
5 = 4800 baud
6 = 9600 baud
7 = 19200 baud
10.4 Modbus parity type 0 - 2 1 1 0 = None 56
1 = Even
2 = Odd
10.5 Modbus time-out 0-3600 1s 0s 0 = No time-out 56
s
10.6 Profibus slave address 2 - 126 1 2 57
10.7 Profibus baud rate 1 - 10 1 10 1 = 9.6 kbaud 57
2 = 19.2 kbaud
3 = 93.75 kbaud
4 = 187.5 kbaud
5 = 500 kbaud
6 = 1.5 Mbaud
7 = 3 Mbaud
8 = 6 Mbaud
9 = 10 AUTO
10.8 Profibus PPO type 1 - 4 1 1 1 = PPO1 57
2 = PPO2
3 = PPO3
4 = PPO4
10.9 Profibus process data1 0 - 99 1 1 57
10.10 Profibus process data2 0 - 99 1 2 57
10.11 Profibus process data3 0 - 99 1 3 57
10.12 Profibus process data4 0 - 99 1 99 57
10.13 LonWorks service button 0 - 1 1 0 57
Table 6-2 Fieldbus parameters, Group 10.
