Page 10 Vacon
Pump and fan control with autochange
6 Special parameters, Groups 2—9
6.1 Parameter tables
Group 2, Input signal parameters
Code Parameter Range Step Default Custom Description Page
2. 1 DIA2 function 0—10 1 11 0 = Not used 20
(terminal 9) 1 = Ext. fault, closing contact
2 = External fault, opening contact
3 = Run enable
4 = Acceler./deceler. time selection
5 = Reverse
6 = Jogging frequency
7 = Fault reset
8 = Acc./dec. operation prohibit
9 = DC-braking command
10 = Motor potentiometer UP
11 = Interlock input, autochange 1
2. 2 DIA3 function 0—10 1 11 0 = Not used 21
(terminal 10) 1 = Ext. fault, closing contact
2 = External fault, opening contact
3 = Run enable
4 = Acceler./deceler. time selection
5 = Reverse
6 = Jogging frequency
7 = Fault reset
8 = Acc./dec. operation prohibit
9 = DC-braking command
10 = Motor potentiometer DOWN
11 = Interlock input, autochange 2
2. 3U
in
signal range 0—210 0 = 0—10 V 21
1 = Custom setting range
2 = 2—10 V
2. 4U
in
custom setting min. 0—100% 0.01% 0.00% 21
2. 5U
in
custom setting max. 0—100% 0.01% 100.00% 21
2. 6U
in
signal inversion 0—1 1 0 0 = Not inverted 21
1 = Inverted
2. 7U
in
signal filter time 0—10s 0.01s 0.1s 0 = No filtering 21
2. 8 I
in
signal range 0—211 0 = 0—20 mA 21
1 = 4—20 mA
2 = Custom setting range
2. 9 I
in
custom setting minim. 0—100% 0.01% 0.00% 21
2. 10 I
in
custom setting maxim. 0—100% 0.01% 100.00% 21
2. 11 I
in
signal inversion 0—1 1 0 0 = Not inverted 22
1 = Inverted
2. 12 I
in
signal filter time 0 —10s 0.01s 0.1s 0 = No filtering 22
2. 13 DIB5 function 0—9 1 6 0 = Not used 22
(terminal 15) 1 = Ext. fault, closing contact
2 = External fault, opening contact
3 = Run enable
4 = Acc./dec. time selection
5 = Reverse
6 = Jogging speed
7 = Fault reset
8 = Acc./dec. operation prohibit
9 = DC-braking command
10 = PI-contr. reference selection
11 = Interlock input, autochange 3
Note! = Parameter value can be changed only when the frequency converter is stopped
(Continues)
