Actual value special display
The
Actual value special display
parameters are used to convert and display the actual value signal
in a form more informative to the user.
The Actual value special display parameters are available in
PID Control Application
and
Pump and
Fan Control Application:
Par ID Parameter name Parameter code in
PID ctrl applic.
Parameter code in
Pump&Fan ctrl applic.
ID1033
Actual value special display minimum
2.2.46 2.9.29
ID1034
Actual value special display maximum
2.2.47 2.9.30
ID1035
Actual value special display decimals
2.2.48 2.9.31
ID1036
Actual value special display unit
2.2.49 2.9.32
Example:
The actual value signal sent from a sensor (in mA) represents the amount of waste water pumped
from a tank per second. The signal range is 0(4)…20mA. Instead of receiving the level of the actual
value signal (in mA) on the display, you wish to receive the amount of water pumped in m
3
/s. You
then set a value for par. ID1033 to correspond to the minimum signal level (0/4 mA) and another
value for par. ID1034 to correspond to the maximum signal level (20 mA). The number of decimals
needed can be set with par. ID1035 and the unit (m
3
/s) with par. ID1036. The level of the actual value
signal is then scaled between the set min and max values and displayed in the selected unit.
The following units can be selected (par. ID1036):
Value Unit On keypad Value Unit On keypad
0 Not Used 15 m3 /h m3/h
1 %
%
16
°F °F
2
°C °C
17 ft ft
3 m m 18 gal / s GPS
4 bar bar 19 gal / min GPM
5 mbar mbar 20 gal / h GPH
6 Pa Pa 21 ft3 / s CFS
7 kPa kPa 22 ft3 / min CFM
8 PSI PSI 23 ft3 / h CFH
9 m / s m/s 24 A A
10 l / s l/s 25 V V
11 l / min l/m 26 W W
12 l / h l/h 27 kW kW
13 m3 /s m3/s 28 Hp Hp
14 m3 /min m3/m
NOTE: The maximum number of characters that can be shown on keypad is 4. This means that in
some cases the display of the unit on the keypad does not comply with the standards.
