4
CONTENTS: PART 1 CONCENTRIC 60/100
Page
The air/flue duct must be installed by a suitably
qualified service provider, which is responsible
for observing the relevant specifications,
regulations and standards.
Requirements
Planning the air/flue duct
layout
Regulations and standards to be observed 5
Alternative termination accessories available 6
Maximum flue lengths for ecoMAX 11
Maximum flue lengths for ecoTEC 12
¤
Installation of the vertical air/flue duct
28
Installation of the horizontal air/flue duct
15
Installation of the black terminal kit
21
Fitting air/flue duct extensions
Installing the air/flue duct sliding sleeve
How to add extensions 31
How to install elbows 32
14
Installation of the variable termination kit
23
