Vaillant ecoTEC plus 618 User Manual

Supplied By www.heating spares.co Tel. 0161 620 6677
9
153
130
390
Fig. 1.11: Flat roof penetration collar
Flat roof penetration collar
Vaillant Accy. No.: 009 056
498
132
255
Fig. 1.9: Adjustable roof tile for pitched roof
Adjustable roof tile for pitched roof
Vaillant Accy. No.: 009 076 (black)
GU_LAZ 41/0
PLANNING THE AIR/FLUE DUCT LAYOUT
Fig. 1.12: Black terminal kit
Black terminal kit for horizontal
air/flue duct
Vaillant Accy. No.: 303 934
For 303 933 and 303 936 only
PART 1 CONCENTRIC 60/100
495
132
495
Fig. 1.10: Flexible pitched roof seal
Flexible pitched roof seal (black)
Vaillant Accy. No.: 303 980
834449_09GB_082006.qxd 10.08.2006 12:20 Seite 9

Vaillant ecoTEC plus 618 Specifications

General

Model	ecoTEC plus 618
Category	Boiler
Output	18 kW
Dimensions	720 x 440 x 338 mm
Fuel Type	Natural Gas
ERP Rating	A
Mounting	Wall-mounted
Warranty	5 years
Boiler Type	Combi
Efficiency	94%
