41
PART 2 CONCENTRIC 80/125
PLANNING THE AIR/FLUE DUCT LAYOUT
498
132
255
Fig. 1.6: Adjustable roof tile for pitched roof
Adjustable roof tiles for pitched roof
Vaillant Accy. No.: 009 076 (black)
GU_LAZ 41/0
164
120
Fig. 1.5: Sliding sleeve, Ø 80/125
Sliding sleeve (PPs), Ø 80/125
Vaillant Accy. No.: 303 215
GU_LAZ 76/0
153
130
390
Fig. 1.8: Flat roof penetration collar
GU_LAZ 42/0
Flat roof penetration collar
Vaillant Accy. No.: 009 056
495
132
495
Fig. 1.7: Flexible pitched roof seal
Flexible pitched roof seal (black)
Vaillant Accy. No.: 303 980
834449_09GB_082006.qxd 10.08.2006 12:20 Seite 41

Vaillant ecoTEC plus 618 Specifications

General

Model	ecoTEC plus 618
Category	Boiler
Output	18 kW
Dimensions	720 x 440 x 338 mm
Fuel Type	Natural Gas
ERP Rating	A
Mounting	Wall-mounted
Warranty	5 years
Boiler Type	Combi
Efficiency	94%
