06 Heat exchanger
ecoTEC plus 824 VUW 246/3-5 + R1
ecoTEC plus 831 VUW 316/3-5 + R1
ecoTEC plus 837 VUW 376/3-5 R1
Pos. Art.-No Part Type, note
02-06-046
01 103409 heat exchanger VUW 246/3-5, with parts 02, 03, 04, 05, 06
01 0020018181 heat exchanger VUW 246/3-5 R1, with parts 02, 03, 04, 05, 06
01 103411 heat exchanger VUW 316/3-5, with parts 02, 03, 04, 05, 06
01 0020018182 heat exchanger VUW 316/3-5 R1, with parts 02, 03, 04, 05, 06
01 0020025040 heat exchanger VUW 376/3-5 R1, with parts 02, 03, 04, 05, 06
02 981227 packingring
03 193595 insulation
04 0020025929 sealing gasket
05 103415 packingring (set of 10)
06 103417 clip (set of 10)
07 - - see main component 08a
08 - - not available as spare part, see pos. 09
09 180985 siphonic condensate trap with part 08
10 180989 support, cpl. (set of 2) with part 11
11 178968 screw (set of 10)
12 - - not necessary
Subject to alteration !
Attention: Please take the gross price from the valid price list !
7

Vaillant ecoTEC plus 824 Specifications

General

Model	ecoTEC plus 824
Category	Boiler
Type	Combination Boiler
Output	24 kW
Dimensions (H x W x D)	720 x 440 x 338 mm
Efficiency	89.3%
Energy Efficiency Class	A
Mounting	Wall-mounted
ERP Rating	A
DHW Output (kW)	24 kW
Maximum Working Pressure	3 bar
Weight	34 kg
Fuel	Natural Gas
Warranty	5 years
