Vaillant ecoTEC plus 824 User Manual

Supplied By www.heating spares.co Tel. 0161 620 6677
4
CONTENTS: PART 1 CONCENTRIC 60/100
Page
The air/flue duct must be installed by a suitably
qualified service provider, which is responsible
for observing the relevant specifications,
regulations and standards.
Requirements
Planning the air/flue duct
layout
Regulations and standards to be observed 5
Alternative termination accessories available 6
Maximum flue lengths for ecoMAX 11
Maximum flue lengths for ecoTEC 12
¤
Installation of the vertical air/flue duct
28
Installation of the horizontal air/flue duct
15
Installation of the black terminal kit
21
Fitting air/flue duct extensions
Installing the air/flue duct sliding sleeve
How to add extensions 31
How to install elbows 32
14
Installation of the variable termination kit
23
834449_09GB_082006.qxd 10.08.2006 12:20 Seite 4

Vaillant ecoTEC plus 824 Specifications

General

Model	ecoTEC plus 824
Category	Boiler
Type	Combination Boiler
Output	24 kW
Dimensions (H x W x D)	720 x 440 x 338 mm
Efficiency	89.3%
Energy Efficiency Class	A
Mounting	Wall-mounted
ERP Rating	A
DHW Output (kW)	24 kW
Maximum Working Pressure	3 bar
Weight	34 kg
Fuel	Natural Gas
Warranty	5 years
