13
PART 1 CONCENTRIC 60/100
Maximum flue length
Maximum flue length
LAS Euro B/S 074/0
LAS Euro B/S 074/0
Fig. 1.18: Horizontal flue systems
Fig. 1.19: Vertical flue systems
PLANNING THE AIR/FLUE DUCT LAYOUT
Concentric flue length
Flue length outside
Fig. 1.20: Horizontal flue system installed with vertical termination kit
834449_09GB_082006.qxd 10.08.2006 12:20 Seite 13

Vaillant ecoTEC plus 824 Specifications

General

Model	ecoTEC plus 824
Category	Boiler
Type	Combination Boiler
Output	24 kW
Dimensions (H x W x D)	720 x 440 x 338 mm
Efficiency	89.3%
Energy Efficiency Class	A
Mounting	Wall-mounted
ERP Rating	A
DHW Output (kW)	24 kW
Maximum Working Pressure	3 bar
Weight	34 kg
Fuel	Natural Gas
Warranty	5 years
