19Operating and Installation Manual for Solar Module VR 68 0020054784_00
h
Note!
If you have confirmed the end of the installation
with "Yes" you can only access the
installation assistant via the code-protected
expert technician operation level (see
installation instructions for VRC 430 or
VRC 430f).
7.2 VRC 430/VRC 430f
Operation level for the expert
technician
Specific operating data can be displayed and adjusted/
changed at the expert technician operation level. This
means that the control system can be perfectly matched
to the solar heating system.
The operation level for the expert technician contains
display screens A1 to A6 in the installation assistant and
also display screens C1 to C26.
Depending on the configuration of the solar heating
system, display screens that are not required are hidden.
The display screens C1 to C26 in the controller VRT430
or VRC 430f in the same sequence as shown in the
following Table 7.2.
This Table shows you which parameters you can adjust
and change.
The installation of the VR 68 solar module in the solar
heating system results in a number of changes to the
standard configuration as described in the manual for
the VRC 430 or VRC 430f; these changes apply for the
following display screens:
C5, C6, C12, C13, C14, C15, C17 and C26.
Start-up 7
