Vaisala AWS430 User Manual

Checking Weather Station Grounding
While visiting the site, check also that the enclosure and the sensor cables are properly grounded.
More Information
‣
Checking Enclosure Grounding (page 6)
‣
Checking Sensor Cabling and Grounding (page 8)
Checking Enclosure Grounding
1. Check that the enclosure grounding cable is connected to the system grounding point.
2
3
4
1
1
Cable lug with hole Ø 6.2 mm (0.24 in)
2 System grounding point
3 AC (mains) cable
4 Enclosure grounding cable
Technical Note M212202EN-A
6 (11)
