5.4.2 Electrical specifications
Power supply
20.4 – 27.6VDC
Power dissipation, no position sensor/loop or
output lamps are connected.
< 2W
Power dissipation, with maximum load on all
inputs and outputs
< 5W, the load not included
Max load per DO11 and DO12
up to 48W @24VDC
If PS2 is not used, total load that can be drawn
from all DO/DI/AI ports (except DO11/12)
2W
