Figure 4: Flow diagram for a partial stroke
Start test
Check start
conditions
Set DO to PST
valve configuration
Check error
conditions
Set DO to
Operationel valve
configuration
Check error
conditions
Stroke is finished
Check warnings
Test finished
sucessfull
Test finished with
error
Test finished with
error
Test finished with
error
Test finished with
error
