4.3 FF – Other Function blocks available but not used in default setting.
Discrete Input (DI)
Discrete input function block, used to receive input data of transducer blocks, and transmit it to
other function blocks.
Configuration
If you want to change the digital input just change the CHANNEL register in the DI Block.
Block
Signal in
Device
OUT_D Values:
Status
DI1
Note: No signals are available on any of the channels.
