Val Controls IHP24-BF User Manual

DHP-UM-013
Val Controls A/S • Limfjordsvej 3 • DK-6715 Esbjerg N • Tel. +45 7547 0600 • Fax +45 7547 0611
vc@valcontrols.com • www.valcontrols.com
Revision: 4
36/58
output to the block to be manually supplied when
simulate is enabled. When simulate is disabled the
simulate value and status track the actual value and
status.
XD_SCALE
[Scaling]
10
1: High Range All the values are associated with the
EU_100
Length 4 byte
Read Write
Value: 100
2: EU_0
Length 4 byte
Read Write
Value: 0
3: Unit Index
Length 2 byte
Read Write
Value: %
4: Decimal point
Length 1 byte
Read Write
Value: 2
Description: The EU_100 high and EU_0 low scale
values engineering unit code, and number of digits to
the right of the decimal point used with the value
obtained from the transducer for a specific channel.
OUT_SCALE
[Scaling]
11
1: EU_100 High Range
Length 4 byte
Read Write
Value: 100
2: EU_0 Low Range
Length 4 byte
Read Write
Value: 0
3: Unit Index
Length 2 byte
Read Write
Value %
4: Decimal Point
Length 1 byte
Read Write
Value: 2
