4-28 Valco Cincinnati, Inc.
Section 4 - Programming
MC075 - MCP-4 Control Unit
Ratio Compensation
Encoder Menu
Screen
Ratio Compensation Pulses/Repeat Length Ratio Compensation Pulses/Repeat Length
Ratio Compensation Pulses/Repeat Length Ratio Compensation Pulses/Repeat Length
Ratio Compensation Pulses/Repeat Length - The scaling factors used to
calculate the correction factor.
If the encoder type “Others” is entered in the Initial Setup (Wizard), it is
necessary to input the encoder parameters on this screen. The following
tables may be helpful:
x2x2
x2x2
x2
