MM113 - D10/D16 Hot Melt Unit Section 10 - Part Number List
143
D10 Unit, Fixed speed, 2H/2G (776xx853) - Previous Version (before 1/2016)
ITEM DESCRIPTION PART NO. QTY.
1 MANIFOLD 776XX111 1
2 FILTER ASSY 593XX499 1
3 VALVE, PRESSURE RELIEF 707XX222 1
4 HEX PLUG 799XX127 11
5 PLUG,PIPE,SOCKET,1/16 NPT 799XX548 4
8 PRESS. GAUGE, 1000 PSI/KG 786XX122 1
9 O-RING 745XX150 2
10 RESERVOIR 776XX114 1
11 VALVE; RESERVOIR SHUTOFF 776XX112 1
12 RING; RETAINING, INTERNAL 783XX277 1
13 HHCS M8 X 90 ZINC 884XX003 4
14 SLW M8 ZINC 784XX476 8
15 GEAR PUMP, STANDARD WIDTH 560XX743 1
16 O-RING 745XX035 2
17 HHCS M8 X 85 ZINC 784XX676 4
18 BLANKET, PUMP INSULATION 776XX061 1
19 CHASSIS 776XX117 1
20 STANDOFF; RESERVOIR 776XX108 4
21 HHCS M8 X 55 ZINC 884XX244 4
22 NUT FLANGE M8 ZINC 884XX243 4
23 BRACKET,MOTOR 775XX856 1
24 HHCS M6 X 14 ZINC 884XX223 4
25 SLW M6 ZINC 798XX593 4
26 GEARMOTOR ASSY 110XX357 1
27 HHCS 1/4-28 X 3/4 ZINC 884XX004 4
28 LOCK WASHER 1/4 ZINC 798XX735 4
29 COUPLING ASSY HEAVY DUTY 783XX322 1
30 CABLE CLAMP 066XX202 1
31 CABLE ASSY; RESERVOIR RTD 029XX549 1
32 CABLE ASSY; RESERVOIR HEATER 029XX550 1
33 SHCS,M5 X 8.0 LNG,B.O. 784XX496 4
34 CABLE ASSY; THERMOSTAT 029XX548 1
35 SHCS M3 X 5 SS. 784XX945 2
36 BLANKET 782XX309 1
37 GASKET; RESERVOIR 782XX310 1
38 CLAMP; HOSE 782XX312 1
39 SCREEN; RESERVOIR 776XX113 1
40 PANEL; HOSE RECEPTACLE 776XX120 1
41 LATCH,SPRING CAM 781XX892 4
To Next Page
