EQUIPMENT DESCRIPTION
2- Technical Data Sheet
CC 450 - CC 470 - CC 490
Cooling capacity 153.600 BTU/h (45 kW) 160.400 BTU/h (47 kW) 167.200 BTU/h (49 kW)
Heating Capacity 153.600 BTU/h (45 kW) 153.600 BTU/h (45 kW) 153.600 BTU/h (45 kW)
Type R134a R134a R134a
Quantity (*) 7,0 kg 7,0 kg 7,0 kg
Model of Blowers Centrífugal Centrífugal Centrífugal
Quantity of Blowers 8 8 8
Air Flow 8.800 m
3
/h 8.800 m
3
/h 8.800 m
3
/h
Nominal Current 72A 72A 72A
Model of Fans Axial Axial Axial
Quantity of Fans 6 6 6
Air Flow 17.400 m
3
/h 17.400 m
3
/h 17.400 m
3
/h
Nominal Current 52A 52A 52A
Model (Alternative Type) TM 65 Bock FK40 655 Bock FK40 755
Displacement 635 CM
3
650 CM
3
755 CM
3
Maximum Rotation Allowed 4.000 RPM 3.500 RPM 3.500 RPM
Lubricating Oil 027-00002-000 027-00002-000 027-00002-000
Quantity Used 1,5 Liters 2 Liters 2 Liters
Type Eletromagnetic Eletromagnetic Eletromagnetic
Tension 24V 24V 24V
(*) The quantity of refrigerant gas for without defroster is 6.7kg.
Equipment without defroster and without bed cabin is 5.7Kg.
