EQUIPMENT DESCRIPTION
2.1- Evaporator Components
NOTE: visit www.reparts.com.br to consult the complet parts catalog.
7
7
6
11
12
13
8
5
10
9
2
1
CC 450 - CC 470 - CC 490
3
4
1 006-00234-000 Left Evaporator Coil - CC450/470/490 1
2 006-00233-000 Right Evaporator Coil - CC450/470/490 1
3 006-00235-000 Right Heating Coil - CC450/470/490 1
4 006-00236-000 Left Heating Coil - CC450/470/490 1
5 012-00055-000 Hot Water Valve - Optional 1
6 012-00181-000 Expansion Valve 2
7 021-00014-000 Radial Fan 24V - with Carbon Brush 8
8 022-00010-000 24V Air Renewal Motor - Optional 1
9 031-00655-000 Liquid Line Tube Set with Defroster 1
10 031-00651-000 Evaporator Suction Tube Set 1
11 034-00401-000 Left Condenser / Evaporator Cover 1
12 034-00400-000 Right Condenser / Evaporator Cover 1
13 041-01445-000 Air Renewal Set - Optional 1
Item Code Qty.Description
