9. Appendix 3 - Configuration Codes
Code
Followed By Space and
Operation
#000
Password
Sends the password for setting serial number etc
#003
Nothing
Returns the Serial number of the unit
#004
New_serial_no<cr>
Changes serial no. in serial eeprom to new_serial_no
floating point number do not use decimal point serial
numbers at the moment.
#007
Output_Format
Sets the output format of the unit to Cal or Nocal
#015
Nothing
Returns the software version of the unit
#020
Sample_rate <cr>
Sets the sample rate of the unit to 2, 4 ,8 or 16 Hz
#021
Nothing
Returns the sample rate of the unit
#028
Nothing
Sets the unit into run mode
#030
Nothing
Returns the output format of the unit [Cal or Nocal]
#170
X_Gain_offset
Sets the zero offset for channel X
#171
Y_Gain_offset
Sets the zero offset for channel Y
#172
Nothing
Returns the zero offset for channel X
#173
Nothing
Returns the zero offset for channel Y
#174
X_Gain_Factor<cr>
Sets the GAIN_FACTOR for channel X
#175
Y_Gain_Factor<cr>
Sets the GAIN_FACTOR for channel Y
#176
Nothing
Returns the GAIN_FACTOR for channel X
#177
Nothing
Returns the GAIN_FACTOR for channel Y
#180
Tx_Mode
Sets the transmit mode to TX (Always)
Or TXDEMAND (Request)
#181
Nothing
Returns the transmit mode of the unit
#184
Em_X_Scaling
Sets the resolution
#185
Nothing
Returns the scaling for X
#186
Em_Y_Scaling
Sets the resolution
#187
Nothing
Returns the scaling for Y
#190
Nothing
Returns the hydro calibration for the X axis
#191
Nothing
Returns the hydro calibration for the Y axis
#192
X_Axis_Calibration
Sets the X Axis Hydro Calibration
#193
Y_Axis_Calibration
Sets the Y Axis Hydro Calibration
#194
Nothing
Returns X DAC cal.
#195
Nothing
Returns Y DAC cal.
#196
X_DAC_cal
Sets X DAC cal.
#197
Y_DAC_cal
Sets Y DAC cal.
#203
Dac_counts
Sets both dac’s to output voltage at desired counts.
#204
Speed
Sets both dac’s to output voltage for desired speed.
#210
Baud Rate <cr>
Sets the baud rate to 2400, 4800, 9600, 19200
