VALMAR Specifications
Page 43
9- Specifications
Model No. 2055
Hopper steel welded, painted with acrylic enamel.
Dimensions Height 50inches, Length 46 inches,
Width 48 inches
Capacity 33 cubic feet; 1485 lbs at 45 lbs per cubic foot density.
Weight (Empty) 700 pounds; hopper with hydraulic fan.
1190 pounds total shipping weight
Gear Box Ratios 60 speed gearbox with 5% difference between settings.
Refer to the chart for more information on ratios.
Tires 6-12 Ground Drive Tire (Approx. 892 revolutions per mile)
Inflate to 30 psi.
Engine Fan Drive Belt driven system. Belt size B70
9 hp Honda Engine with centrifugal clutch
Hydraulic Fan Drive Belt driven system. Belt size BX75
2.8 cubic in./rev. motor. Minimum flow requirement is 10 gpm (U.S.) for a fan
speed of 3800 rpm.
Metering Two metering rollers with shut of gate for each roller.
20 venturis. Manifold and venturis drop for easy calibration and emptying.
Electric Clutch 12 volt DC; 3.4 amps; 90 lbs torque capacity. Resistance is 2.4 to 2.8 ohms
(cold). Two clutches for complete or ½ shutoff of metering rollers and in-cab
control unit.
Electrical 12 volt D.C.; 10 amps standard version; 20 amps alternate version
Requirements
Operating Width 50 feet maximum @ 30 inch deflector spacing.
Metering Gearbox Ratios: (input to output shaft)
No. 1 No. 2 No. 3 No. 4 No. 5 No. 6 No. 7 No. 8
A
B A B A B A B A B A B A B A B
Input
Gear
.250 .265 .276 .292 .305 .321 .336 .353 .371 .388 .409 .427 .451 .471 .498 U. Low
.498 .528 .551 .581 .608 .640 .670 .704 .739 .774 .815 .852 .899 .938 .993 Low
1.007 1.066 1.112 1.174 1.227 1.292 1.353 1.421 1.492 1.563 1.645 1.720 1.816 1.895 2.006 Med.
2.007 2.125 2.217 2.341 2.447 2.576 2.698 2.833 2.975 3.117 3.281 3.430 3.620 3.778 4.000 High
