Valmar 3255 - User Manual

Questions and Answers

R
reneekingAug 16, 2025
What to do if the venturi is filling up with product and spilling over on my Valmar 3255 Farm Equipment?
- D
  drodriguezAug 16, 2025
  If the venturi is filling up with product and spilling over in your Valmar Farm Equipment, consider these potential causes. The fan inlet might be plugged, so unplug it. The fan speed could be too low; increase the fan speed to 17 inches water column pressure. Inspect the fan to manifold hose for tears or operational issues; replace the hose if necessary. Ensure the fan is operating and engage the fan drive if it isn't. The manifold pressure gauge might be giving an inaccurate reading, so replace it. The manifold could be plugged; clean it out. The product might be caking up in the venturi; clean the venturi. Also, clean out the hopper if there is water in it and run the fan to blow-dry the delivery system if there is water in the manifold.
A
Austin TaylorAug 19, 2025
Why is product shooting out of the venturi of my Valmar 3255 Farm Equipment?
- C
  Christopher MurphyAug 20, 2025
  If product is shooting out of the venturi due to back pressure in your Valmar Farm Equipment, it could be due to a few reasons. Check for obstructions in the delivery hoses and unplug them if necessary. A collapsed delivery hose could also be the culprit, so replace the hose if it is. The fan speed might be too low, so increase it to 17 inches water column pressure. Finally, your field speed might be too fast, causing the product to be metered into the venturis faster than the airflow can carry it, so slow down.
M
Michael HayesAug 23, 2025
What to do if the clutches will not engage on my Valmar 3255?
- M
  Monica WilsonAug 23, 2025
  If the clutches on your Valmar Farm Equipment will not engage, start by checking the power cable to the battery, fuses, wiring harness, and all connections to ensure there is electrical power to the clutches. If there is dirt lodged between the clutch halves, pull the clutch halves apart, clean the contact surfaces, and reset to the proper gap. Finally, if the gap between the clutch halves is too wide (should be 1/32”), disassemble the clutch and remove the spacer ring.
C
Christopher BoydAug 27, 2025
How to stop static electricity from making product cling to the venturi in my Valmar 3255?
- D
  Danielle McmillanAug 27, 2025
  If product clings to the venturi due to static electricity in your Valmar Farm Equipment, it's likely because an electrical charge is building up in the venturi. Clear the venturi by pushing the product through with the fan running. Wipe the venturi with an antistatic towel. If the problem persists, ground the venturi to the manifold by running a small wire, preferably copper, through the venturi cup and into the manifold, ensuring the wire contacts the manifold.
B
Brian SanchezAug 31, 2025
Why is the speed fan too slow on my Valmar 3255?
- J
  Jaime GutierrezAug 31, 2025
  If the speed fan is too slow on your Valmar Farm Equipment, first check if the fan drive belt is loose and adjust the tension if needed. Next, ensure the flow control valve is properly set. Finally, verify that the tractor is providing sufficient oil supply by checking the hydraulic oil flow specifications for the tractor and ensuring that the tractor hydraulic system is working properly.
R
ruthcollinsSep 4, 2025
What causes hydraulic motor leaks in Valmar 3255?
- N
  nicole64Sep 4, 2025
  If your Valmar Farm Equipment's hydraulic motor is leaking, it could be due to several reasons. The seal might be worn or damaged by heat, or overpressure might have ruptured the seal. Alternatively, contaminants could have damaged the seal. In any of these cases, replace the seal. Also, ensure that the oil supply is clean to prevent future damage from contaminants.
W
Wayne KnappSep 7, 2025
Why does the hydraulic fan drive surge and/or overheat in my Valmar 3255?
- R
  Rhonda PottsSep 8, 2025
  If the hydraulic fan drive surges or overheats on your Valmar Farm Equipment, it might be because the Valmar flow controller is incompatible with your tractor’s hydraulics. In this case, install a Valmar flow control bypass kit.
F
fmarshallNov 11, 2025
Why is the application rate lower than expected on my Valmar Farm Equipment?
- A
  Ashley MeyerNov 11, 2025
  If the rate of product being applied by your Valmar Farm Equipment is lower than expected, several factors could be at play. First, the product density may have changed, causing a discrepancy with the applicator charts; in this case, you should calibrate your applicator and create a new chart. A mathematical error could have occurred during calibration, so recheck your calculations. Also, verify that you accurately weighed the calibration sample. Furthermore, the actual acreage covered may be less than expected; recheck the field size, keeping in mind that tractor wheel slippage can cause an incorrect odometer reading. Ensure the gearbox setting is correct and that the sprockets aren't slipping on the shafts. Also, check if the ground drive wheel is slipping or if misaligned shafts and spr...

Summary

Introduction

Safety Alert Symbol

Symbol indicating important safety messages in the manual.

Dealer Information

Contact information for parts and service support.

Operator Orientation

Defines directions (left, right, front, rear) from the driver's seat.

Safety

Signal Words

Explains DANGER, WARNING, and CAUTION signal words used on decals.

Operator Safety

Safety for operators and towed implements.

Serial Number Location

Applicator Serial Number

Location of the serial number plate on the applicator.

Operation

Safe Operation & Pre-Operation Checklist

Essential safety procedures and checks before operating the applicator.

Control Unit and Settings

Operation of the control unit, switches, and rate adjustments.

Fan Drive Operation

Details on gas engine and hydraulic fan drive systems.

Metering System & Application Rate

Setup and adjustment of metering rollers and application rates.

Calibration

Calibration Set Up

Steps for setting up the applicator for calibration.

Calibration Procedure

Steps and table for performing the calibration process.

Calibration Results

How to interpret calibration results and identify potential issues.

Flow Rate Charts

Charts providing flow rates for various products and settings.

New Product Calibration

Procedure for calibrating products not listed in standard charts.

Adjustments & Service

Safety Guidelines for Service

General safety precautions for performing maintenance and adjustments.

Electric Clutch Service

Troubleshooting and servicing electric clutches.

Centrifugal Clutch and Bearings

Maintenance and replacement of the centrifugal clutch and bearings.

Fan Drive Maintenance

Procedures for ensuring proper fan drive operation and maintenance.

Gearbox and Shifter Adjustments

Adjusting gearbox alignment, idler tension, and shifter settings.

Metering Roller System Service

Cleaning, gap adjustment, and maintenance of metering rollers.

Lubrication and Drive System Maintenance

Lubrication, belt/chain adjustments, alignment, and fan drive tension.

Seasonal Maintenance Procedures

Tasks for post-season and pre-season maintenance.

Troubleshooting

Product Application Rate Issues

Solutions for rates lower than expected or incorrect calculations.

Gearbox and Drive System Issues

Troubleshooting for wrong gearbox settings, slipping sprockets, or drag.

Venturi and Hose Issues

Solutions for product shooting out or venturi filling issues.

Static Electricity and Clutch Issues

Resolving issues with product clinging due to static or clutches not engaging.

Fan Speed and Hydraulic Issues

Troubleshooting slow fan speed, hydraulic motor leaks, and overheating.

Options

Pedestal Mount Kit

Kit for installing applicator over obstructions.

Alternate Rate Kit

Kit for switching between two application rates.

Gas Engine Kit

Kit for a gas engine fan drive.

Flow Control Bypass Kits

Kits to address surging/heating issues with hydraulic fan drive.

Hose Coupler Kit

Kit for temporarily removing applicator from implement.

Outlet Blocker Kit

Kit to block off specific outlets on metering bottoms.

Harrowbar Mounting Kits

Mounting kits for harrowbar applications.

Specifications

Model 2055 Specifications

Detailed technical specifications for the Valmar 2055 applicator.

Model 2455 Specifications

Detailed technical specifications for the Valmar 2455 applicator.

Model 3255 Specifications

Detailed technical specifications for the Valmar 3255 applicator.

Electrical Wiring Diagrams

Diagrams illustrating control unit, implement harness, and clutch wiring.

Parts

Fan Assembly Parts

Exploded views and part numbers for the fan assembly.

Fan Drive System Parts

Exploded views and part numbers for engine and hydraulic fan drives.

Bottom and Manifold Parts

Exploded views and part numbers for bottom and manifold assemblies.

Metering Roller Parts

Exploded views and part numbers for metering roller components.

Gearbox Assembly Parts

Exploded views and part numbers for the gearbox assembly.

Clutch Assembly Parts

Exploded views and part numbers for clutch assemblies.

Hopper Assembly Parts

Exploded views and part numbers for the hopper assembly.

Deflector Mounting Parts

Exploded views and part numbers for deflector mounting.

Ground Drive Assembly Parts

Exploded views and part numbers for the ground drive assembly.

Decals

List of safety and informational decals available for the applicator.
