VALMAR Specifications
Page 45
Tires 6-12 Ground Drive Tire. Approx. 892 revolutions per mile. Inflate to 30 psi.
Engine Fan Drive Belt driven system. Belt size B70
11 hp Honda Engine with centrifugal clutch.
Hydraulic Fan Drive Belt driven system. Belt size BX75
2.8 cubic in./rev. motor. Minimum flow requirement: 11.5 gpm (U.S.) for a fan
speed of 4200 rpm.
Metering Two metering rollers with shut of gate for each roller.
32 venturis. Manifold and venturis drop for easy calibration and emptying.
Electric Clutch 12 volt DC; 3.4 amps; 90 lbs torque capacity. Resistance is 2.4 to 2.8 ohms
(cold). Two clutches for complete or ½ shutoff of metering rollers and in-cab
control unit.
Electrical 12 volt D.C.; 10 amps standard version; 20 amps alternate version
Requirements
Operating Width 80 feet maximum @ 30 inch deflector spacing.
Figure 8- 1: Dimensions
