16
Magnetothermic differential FUSES (slot 3 mm) of appropriate dimensions
must be installed between the electricity network and the MAIN SWITCH.
model
max. current
fuse type
Easy 3 TTi
16A
SLOW
Easy 4 TTi
16A
SLOW
The position of the MAIN SWITCH with the FUSES in the power circuit scheme
of the appliance:
