275 software tree
Calibration with 275 HART® user interface with SMART-PULP
instruction set (SMARTPULP DLL)
BCs160VA
Nov. 15, 1997
SMART-PULP Smart Consistency Transmitter
Measurement
Configuration
Calibration
Diagnostics
PV %Cs
Active recipe
Sensor tmp.
Process tmp.
Housing tmp.
AO mA
Shear F.
% of range
Range values
Detailed config.
Device info
New recipe
Sampling
Lab results
Special grade
Tmpr. calib.
Loop test
Device status
Low Rnge
Upp Rnge
LSL
USL
Min. span
Damping
Alarm current
Mounting
Blade type
Blade material
Poll addr
Manufacturer*
Model*
Sensor ser.n:o*
Tag
Message
Universal rev.*
Fld dev rev.*
Software rev.*
Hardware rev.*
Descriptor
Date
Device code
Final asbly num*
Recipe 1
...
...
Recipe 8
Pulp Ty
Filler %
P1
P2
Start sample 1
Start sample 2
Recipe n:o
Use frst /sec /both
Filler %
Enter lab. cons.
OK
#1 %Cs
#1 Offset
....
....
#16 %Cs
#16 Offset
Sensor
Process
Housing
* = Fixed
