Valmet SMART-PULP - Page 39

BCs160VA
Nov. 15, 1997
SMART-PULP Smart Consistency Transmitter
39
Figure 6 Dimensions
MODE
ENT ER
COMM COMM
TEST+
TEST-
100
85
78
226
198
23
H
242
HL: 50
WS: 355
126
72
78
78
140
80
110
Sensor Dimension H
(from edge of coupling)
LL 95
LS 70
UL 95
GL 95
RL 95
JL 95 Standard coupling
JL 57 Plastic-pipe coupling
HL 60 Standard coupling
HL 38 Blow line coupling
WS 75
SMART-PULP with
local operator
terminal
SMART-PULP without operator
unit. Used with remote operator
terminal
SMART-PULP’s remote operator terminal.
Length of connecting cable: 9.75 m.
