VCWS08 TROUBLE SHOOTING TABLE
MARCH 15, 2003 TO PRESENT
PROBLEM POSSIBLE CAUSE SOLUTION
1) BLOWN FUSE REPLACE FUSE
2) DEFECTIVE SPEED
CONTROL
REPLACE SPEED
CONTROL REFER TO
SECTION 8I
3) BREAK IN WIRES REWIRE, REFER TO
DIAGRAM 9.2
7A VCWS08 WILL NOT
RUN
4) DEFECTIVE MOTOR REFER PROBLEM TO
VALPAR CUSTOMER
SERVICE
1) SPEED ADJUSTED
INCORRECTLY
ADJUST WHEEL SPEED
REFER TO SECTION 8C
OR 8D
2) DEFECTIVE SPEED
CONTROL
REPLACE SPEED
CONTROL REFER TO
SECTION 8I
3) DEFECTIVE LAZY
SUSAN
REFER PROBLEM TO
VALPAR CUSTOMER
SERVICE
7B VCWS08 RUNS BUT
THE SPEED IS
ERRATIC OR HAS
JERKEY MOTION
4) DEFECTIVE MOTOR REFER PROBLEM TO
VALPAR CUSTOMER
SERVICE
1) IMPROPER
MICROSWITCH BEND
REALIGN
MICROSWITCH REFER
TO SECTIONS 8E, 9.3, 9.4
2) MICROSWITCH
DEFECTIVE
REPLACE
MICROSWITCH REFER
TO SECTION 8E
3) COUNTER
DEFECTIVE
REPLACE COUNTER
REFER TO SECTION 8F
7C VCWSO8 RUNS BUT
DOES NOT COUNT
4) BREAK IN WIRES REWIRE, REFER TO
DIAGRAM 9.2
