2.3.2 Driving controls
1 2 3
9
7
8
10
5
16
12
14
15
13
3
11
1
2
4
6
GUID-FAAE4207-5CC0-46C5-ACA4-28BC6A3095D8
1. Change switch for A-pillar display views
2. Activation/recording switch for U-Pilot
3. Switches for cruise control
4. Switch for four-wheel drive (4WD)
5. Switch for differential lock
6. Switch for front suspension (alternative equipment)
7. Switch for shifting automatics
8. Switch for automatic traction control
9. STOP indicator light (red)
10. Lever for creeper speed range
11. HiShift push button
12. Push buttons for Powershift operation
13. Engage/pause button for U-pilot
14. Stop button for U-pilot
15. Push buttons for cruise control
16. Hand throttle
2. Instruments and controls
- 27 -
