2.3.3 Linkage
Rear linkage
GUID-82DDBCD8-450A-40D6-A7B1-C669CD96B983
1. Diagnose light
2. Lowering speed selector
3. Lifting height selector
4. Draft control selector
5. Drive balance control, including slip control system
6. Lift/lower push buttons
7. Lift/lower indicator lights
8. Drive balance control light
9. Slip control light
10. Switch for trailer hitch latch hydraulic releasing (extra equipment)
11. Lift/stop/lower switch
12. Passing switch for position control knob
13. Position control knob
Front linkage
Front linkage is extra equipment.
2. Instruments and controls
- 28 -
