INTRODUCTION
The Evolution by Vanco EVEXFBR1 HDMI Extender with bi-directional IR and RS-232, extends 4K HDR video and audio
signals up to 984ft/300M over multi-mode ber optic cables, and 6.2mi/10km over single mode ber optic cables and
modules! Bi-directional IR pass-through allows for source and/or display control. Also features RS-232 pass-through for
additional control. For extending HDMI with 4K HDR resolution at an extreme distance, the EVEXFBR1 is a great solution
for any application.
The EVEXFBR1 includes two units: transmitting unit (EVEXFBR1-TX) and receiving unit (EVEXFBR1-RX). The transmitting
unit is used to capture the HDMI input with control signals and carries the signals via ber optic cables. The receiving unit
is responsible for equalizing the transmitted HDMI signal and reconstructing IR signals. Both units require power.
FEATURES
• Transmits audio and video via HDMI as well as bi-directional IR and RS-232
• Transmission range: 984ft/300m over multi-mode ber optic cables; 6.2mi/10km over single mode ber
optic cables
• Supports 4K@60Hz, 4:2:0 chroma sampling and HDR; 4K@60Hz and 4:4:4 chroma sampling
• Supports HDR10 and Dolby Vision
• Features bi-directional IR (20kHz to 60kHz) pass-through for source and/or display control
• RS-232 pass-through
• Supports HDCP2.2
• Multi-mode SFP modules included
• Dimensions: 4.9” W x 4.4” H x 1.1” D
HDMI® Extender over Fiber with IR and RS-232
Part # EVEXFBR1
PACKAGE CONTENTS
• EVEXFBR1 (TX & RX)
• (1) IR Transmitter
• (1) IR Receiver
• (2) DC 12V Power Supply
• (2) Multi-mode SFP Modules
• Product Manual
