Name Description
MODE Select Linked or Flexible. Linked mode reduces the number of options available in the
Expander Edit menu.
INPUT Select the zone
Editing Keyswitch Expanders
The following table lists the available options for keyswitch expanders:
Name Description
DESCRIPTION Enter or edit a description for the expander.
LOCATION Select a location for the expander from the list of defined areas.
LATCH Enable or disable the latch on the key position.
VISUAL
INDICATIONS
(Flexible mode
only)
Enables you to assign specific behaviour to each LED on the keyswitch expander. Each of
the LEDs has the following options:
l FUNCTION — the following options are available:
– KEYSWITCH — select a keyswitch and the position of the key.
– DISABLED — select to disable the LED.
– SYSTEM — select the alarm type which triggers the LED.
– AREA — select the area which triggers the LED.
– ZONE — select the zone which triggers the LED
– DOOR — select the door and the door option which triggers the LED.
l ON – COLOR — specify the activation colour
l ON – FLASH — specify the behaviour of the LED in active state. Available options are:
– Permanent — always on.
– Flash Fast/Medium/Slow — varying speed of the flashing.
l OFF – COLOR — specify the deactivation colour.
l OFF – FLASH — specify the behaviour of the LED in the inactive state. Available options
are:
– Permanent — always on.
l Flash Fast/Medium/Slow — varying speed of the flashing.
DEACTIVATION
(Flexible mode
only)
Select a deactivation method from the available options:
l Calendar — select a calendar.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the keypad
© Vanderbilt 2018 131 A6V10276959-d
11.2018
