EN50131 Requirement (and relevant section) Relevant Vanderbilt documentation
Installation, commissioning and maintenance instructions,
including terminal identifications
Mounting system equipment on page43
Controller hardware on page68
Type of interconnections (see 8.8) Technical data:
l SPC4000 on page31
l SPC5000 on page33
l SPC6000 on page37
Wiring the X-BUS interface on page75
Details of methods of setting and unsetting possible (see 11.7.1
to 11.7.3 and Tables 23 to 26)
User programming via the keypad:
l Setting/Unsetting on page275
l Configuring a Keyswitch Expander on
page242
l Configuring wireless fob devices on
page110
l Triggers on page288
Serviceable parts Technical data:
l SPC4000 on page31
l SPC5000 on page33
l SPC6000 on page37
Power supply requirement if no integrated PS See installation instructions for SPCP33x and
SPCP43x Expander PSUs.
Where PS is integrated, the information required by EN 50131-
6:2008, Clause 6
Technical data:
l SPC4000 on page31
l SPC5000 on page33
l SPC6000 on page37
Maximum number of each type of ACE and expansion device. Wiring the X-BUS interface on page75
Technical data:
l SPC4000 on page31
l SPC5000 on page33
l SPC6000 on page37
Current consumption of the CIE and each type of ACE and
expansion device, with and without an alarm condition.
See relevant installation instructions.
Maximum current rating of each electrical output Technical data:
l SPC4000 on page31
l SPC5000 on page33
l SPC6000 on page37
