Configure Advanced ATP Settings
WARNING: It is not recommended to change Advanced ATP Settings. Changes must only be
made by expert users.
1. Click the Advanced ATP Settings button.
2. Configure the fields described in the table below.
ATP Connections
Active ATP
Connection
Select the ATP connection type when the ATP is operating as the primary
communication path.
l Permanent: Stay Connected
l Temporary: Hangup 1second
l Temporary: Hangup 20 second
l Temporary: Hangup 80 second
l Temporary: Hangup 3 minutes
l Temporary: Hangup 10 minutes
l Temporary: Hangup 30 minutes
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 311 A6V10276959-d
11.2018
