Event
Message
Minimum length of an event and test call message.
l 0 Bytes
l 64 Bytes
l 128 Bytes
l 256 Bytes
l 512 Bytes
Other
Message
Minimum length of connection and encryption key and update messages.
l 0 Bytes
l 64 Bytes
l 128 Bytes
l 256 Bytes
l 512 Bytes
3. Click Save.
Add ATP to Analog ARC
If a connection between the SPC panel and RCT (for example, SPC Com XT) goes down, FlexC has
the ability to switch to a backup ATP connection between the SPC panel and an Analog ARC. You can
configure up to 10 ATPs for each ATS.
1. To configure an ATP between an SPC panel and an Analog ARC, click the button Add ATP to
Analog ARC.
2. Complete the ATP fields described in the table below.
Panel Identification
ATP Sequence
No.
This field displays the sequence number of the ATP in the ATS
configuration. Number 1 is primary, numbers 2–10 are backup
ATP Unique ID This ID uniquely identifies the ATP to the RCT
ATP Name Enter a name for the ATP
SPT Account
Code
Enter a number to uniquely identify the panel to the RCT (1–999999)
ARC Connection
Number 1 Phone number 1
Number 2 Phone number 2
Modem Select Select the modem to be used.
l Modem 1
l Modem 2
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 314 A6V10276959-d
11.2018
