7.1.2.1 Installing Batteries
This section describes the battery installation for the SPCP355.300 Smart PSU and G5 Housing.
Number Description
1 Battery
2 Battery strap
3 Fixing holes
4 Strap holes
5 Battery leads
6 Battery temperature leads
7 PSU/Expander
8 Mounting positions for additional expanders.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Smart PSU
© Vanderbilt 2018 61 A6V10276959-d
11.2018
