O&M-V5-FAP-AVF-LCD R0
Operator’s Manual (Fire Alarm Panel c/w AVF & LCD)
Pg 4 of 21
d) Disabled (Amber) : General Disabled Indicator, system in disabled
condition
e) System Fault (Amber) : Indicate Programmable Micro Controller failure
f) Fire Sent (Red) : Fire Signal to Alarm Remote Monitoring Station
activated (Optional)
g) Fire Line Trouble (Amber) : Fire Signal Line open/short (Optional)
(Note: It shall not be suppressed during the Fire Alarm condition)
h) Fault line Trouble (Amber) : Fault Signal Line open/short (Optional)
i) Sounder Fault (Amber) : Alarm sounder line open/short
(Note : It shall not be suppressed during Fire Alarm condition)
j) Earth Fault (Amber) : Field input/output wires shorted to ground
k) Auxiliary Fault (Amber) : Auxiliary supply / auxiliary supervised line open/short
l) Mains Failure (Amber) : 230V AC Mains supply failure
m) Charger fault (Amber) : Charger Fuse blown / charger voltage (low / high)
n) Battery Fault (Amber) : Battery supply disconnected / battery fuse blown /
battery voltage (low / high)
o) Alarm Counter (3x7Seg.) : Indicate that number of alarm (false) been activated
(for FALSE Alarm Management)
p) AVF Off (Amber) : Indicate that AVF function been set off
q) Retard State (Amber) : Indicate that system in Retard State
r) Confirmation State (Amber) : Indicate that system in Confirmation State
Control Switches
a) Buzzer Silence (Black) (1) : To silence fault buzzer (Audio & Visual)
b) Sounder Silence (Amber) (2) : To silence alarm sounder (Audio & Visual)
c) System Reset (Brown) (3) : To normalise the system
(Note: Silence alarm sounder before RESET)
d) Indicators Test (White) (4) : To test the working condition of all LED
indicators and buzzer
e) Auxiliary Disable (Blue) (5) : To disable auxiliary output control function
(Audio & Visual)
f) Sound Alarm (Red) (6) : To raise alarm sounder manually for
emergency evacuation (Audio & Visual)
