O&M-V5-FAP-AVF-LCD R0
Operator’s Manual (Fire Alarm Panel c/w AVF & LCD)
Pg 9 of 21
d) No outputs are activated (FIRE output, external Alarm Bells/ Aux output)
e) When Retard State (20 sec) lapses, Retard State LED go off
f) “CONFIRMATION STATE” LED (Amber) lighted (120sec)
During Confirmation State (120sec)
a) If no alarm activated, panel back to normal condition itself when Confirmation State (120 sec)
expire
b) If any zone goes into alarm, panel goes into FIRE condition
2.8 LCD Event Logging Module (LLM)
LCD Event Logging Module (LLM) is provided as add on feature to display and record
the activated alarm zone information complete with date and time.
LLM is integrated with non-volatile memory (EEPROM) to store and record the activated
alarm zone event up to 999, it will not be lost even the system total power failure. The
recorded zone alarm event are essential for the FALSE ALARM MANAGEMENT.
LLM is also incorporated with backup battery for real time clock, it will be continuous
running during the system total power failure.
LLM is operated by Micro Controller Processor Unit, it is fully supervised and monitored
for the software processing. In the events of Processor fault, and audio & visual signal
will be given. The failure of the Porcessor will not impair the Primary Function of
the Fire Alarm System.
2.8.1 MENU Function
It is provided easy and user friendly operation.
MENU
VIEW FIRE ARCHIVE
PRINT FIRE ARCHIVE
SETUP
PNL ADR
TIME
DATE
DELETE
