2.8.1.a VIEW FIRE ARCHIVE
To view the recorded alarm zone event;
a) Press “Menu”
b) Select “VIEW FIRE ARCHIVE” by “Up” / “Down” key and press “Enter”
(017TC: Total Event Counter “017”, Fire)
(017: 17
th
event of 017TC, M00-Z005: “Main” panel address “000” Zone “005” Fire) at
(02/04/06: 2
nd
April 2006, 15:32:12: 3:32:12PM)
c) The rest recorded event are able to view by manual action (Down/Up key)
2.8.1.b PRINT FIRE ARCHIVE
To print the recorded alarm zone event;
a) Connect the Printer
b) Press “Menu”
c) Select “PRINT FIRE ARCHIVE” by “Up” / “Down” key and press “Enter”
Print start from (017/TC017: 17
th
event of Total Event Counter “017”)
d) Select the starting event by “Up” / “Down” key and
e) Press “Enter”, Printer will start print the backward event until the last event
“000” and stop
f) During the printing: to stop the print, press “Escape”
2.8.1.c SETUP
To setup the panel;
a) Press “Menu”
b) Select “SETUP” by “Up” / “Down” key and Press “Enter”
c) Select the required setup function by “Up” / “Down” key and Press “Enter”
017TC FIRE
017 M00-Z005
02/04/06 15:32:12
PRINT FROM
017/TC017
PNL ADR
TIME
DATE
DELETE
PRINTER
