O&M-V5-FAP-AVF-LCD R0
Operator’s Manual (Fire Alarm Panel c/w AVF & LCD)
Pg 11 of 21
(1) PNL ADR: To set the Panel Address, select by “Up” / “Down” key and
press “Enter” to save
(e.g. M000: Main Panel Address 000, S001: Sub Panel Address 001)
(2) TIME: To set the Time, select the time by “Up” / “Down” key and
press “Enter” to save (Hour:Minute:Second – 24Hr System)
(3) DATE: To set the Date, select the Date by “Up” / “Down” key and
press “Enter” to save (Day:Month:Year)
(4) DELETE: To delete the recorded event, key in the password and press
press “Enter” (Delete all recorded event)
(Password and Access Level control is provided to prevent unauthorized
system control and alteration of alarm event recorded.)
(5) PRINTER: To Enable / Disable the printer for on-line printing,
select Enable / Disable by “Up” / “Down” key and
press “Enter” to save
PANEL ADDRESS M000
PRESS ENTER TO SAVE
HH:MM:SS
19:46:22
DD/MM/YY
10/04/06
?????
PASSWORD
PRINTER
[ENABLE] DISABLE
To Next Page
