Vanguard V5 - Technical Specification

O&M-V5-FAP-AVF-LCD R0
Operator’s Manual (Fire Alarm Panel c/w AVF & LCD)
Pg 20 of 21
TECHNICAL SPECIFICATION
Fire Alarm Panel
S/N I/P – O/P Description Capacity / Rating
End Of
Line
Resistor
(EOLR)
Feature
1 ZONE - Min 4 Zones
(Multiple of 4 Zones)
- Max 136 Zones
- 40 Heat or 20 Smoke
Detectors per Zone
- Max 2.4 mA per Zone
- Wire: 1.5mm
2
6.8K Ohm - Line Open / Short supervised
2 ALM - 1 Output - DC 24V
- Fuse: Max 2Amp
- Wire: 2.5mm
2
6.8K Ohm - Line Open / Short supervised c/w
Fuse Protection
- Expendable by additional module
3 ALM – 2 Output - DC 24V
- Fuse: Max 2Amp
- Wire: 2.5mm
2
6.8K Ohm - Line Open / Short supervised c/w
Fuse Protection
- Option for “Supervised Auxiliary”
function provided
- Expendable by additional module
4 AUX – 1 Output - C, NC, NO Contact
(Max DC 24V, 5Amp)
- Wire: 2.5mm
2
- - Option for “Voltage Contact”
selection provided
5 AUX – 2 Output - C, NC, NO Contact
(Max DC 24V, 5Amp)
- Wire: 2.5mm
2
- - Option for “Voltage Contact”
selection provided
6 To MAP Output - Wire: 1.5mm
2
- - For SAP : Common Fire & Fault
signal to Main Alarm Panel (MAP)
Zone
7 FIRE Output - C, NC, NO Contact
(Max DC 24V, 1Amp)
- Wire: 1.5mm
2
- - Common Fire Volt-Free Contact
Output
8 FAULT Output - C, NC, NO Contact
(Max DC 24V, 1Amp)
- Wire: 1.5mm
2
- - Common Fault Volt-Free Contact
Output
9 AUX 24V DC Output - DC 24V
- Fuse: Max 2Amp
- Wire: 2.5mm
2
- - Constant 24V DC Output c/w Fuse
Protection
10 G-ALM OP-IP Terminal - Wire: 1.5mm
2
-
11 G-SIL OP-IP Terminal - Wire: 1.5mm
2
-
12 G-RST OP-IP Terminal - Wire: 1.5mm
2
-
13 G-AUX OP-IP Terminal - Wire: 1.5mm
2
-
- General Alarm, Silence, Reset and
Auxiliary control function
(MAP to SAPs common connection)
Alarm Remote Monitoring Station (Optional)
14 FIRE Output - Max DC 24V, 120mA
- Wire: 1.5mm
2
- Line Open / Short supervised
15 FAULT Output - Max DC 24V, 120mA
- Wire: 1.5mm
2
Signal to Alarm
Monitoring
Transmitter
Panel
- Line Open / Short supervised
- Normally energized output
(for Panel Total Failure signal)
Remark:
Terminal Wire Range : 24-12AWG 2.5 mm
2
