The electrical system on your PineCrest FW. is comprised of two independent electrical systems. One system is 120-volt
60hz AC power, and the other is 12-volt DC power.
All instalations meet or exceed industry standards applicable on the date of manufacture. The electrical equipment
and associated circuitry are engineered into a dedicated system specific to your RV. Unauthorized changes or adding
fixed appliances is NOT recommended. Changes or additions made after delivery may result in a hazardous condition.
Service and/or modification of the RV electrical system should only be performed by qualified electrical technicians.
The methods, components, and materials used must be in compliance with current safety and code requirements.
Please consult your dealer’s service department for assistance.
Electrical System Maintenance
• ALWAYS disconnect the negative 12-volt DC battery terminal and the shore power cord BEFORE working on the
electrical system.
• ALWAYS turn OFF the power converter, BEFORE disconnecting the battery.
For more information on your RV's electrical system, See the component manuals in your Owner Information Package.
50
-
AMP POWER CORD
The power cord (or shore power cord) connects your RV to an external power receptacle. This heavy-duty cord has a
dual purpose.
• It carries voltage and current to your RV from the external power receptacle, and
• Grounds your RV electrical system through the external power receptacle.
ALWAYS test the external power receptacle (or electrical box) with a Ground Monitor BEFORE connecting your
power cord.
NEVER connect the power cord if the ground monitor indicates reverse poarity or an open ground.
Connecting the power cord
1. Turn OFF the load center main 120-volt circuit breaker.
2. Carefully extend the entire length of the power cord from the electric cable hatch to the external power source.
3. Plug the power cord into the receptacle. Make sure that all of the power cord prongs are properly seated into the
receptacle.
4. Return to your RV and turn ON the load center main circuit breaker.
