5 Instructions for use.
5.1 Machine assembly.
Ask your seller to provide unpackaging of the machine and briefing.
Grip points:
a) Front: - Mowing disk or lower casing;
b) Rear: - Handlebar grips or machine frame end tubes with handlebars tipped.
If you assemble the machine yourself, follow the below instructions:
1. Take the machine out from the box and all parts from the packages.
(other procedures see Figure 2)
2. Unloose the plastic rosettes in the handlebars joints and turn the handlebars so
that they point to the rear of the machine. Adjust the handlebar height so that you
comfortably get up to it. Tighten the rosettes.
3. Fix the Bowden cables to the handlebars by using plastic tightening tapes.
4. Slide the apron with the holder into the holder on the frame and secure it by
tightening the plastic rosette with bolt.
Travel wheels
Engine
