VARI XP-200
3.1.4 Brake flywheel
Brake flywheel off the engine. In order to start the engine, the
lever must brake the flywheel in position 1 . To stop the engine
must be the flywheel brake lever in position 2 .
3.1.5 Recoil starter grip
Pulling the starter grip operates the recoil starter to crank the
engine.
Gently pull the starter handle and when you feel resistance,
strong pull.
Note: After starting, do not let starter handle. Handle not bump
back into the engine. Appropriate precautions to prevent damage to
the starter.
3.2 Principle
Fuel burn in the engine block, convert heat energy by piston motion.
3.3 Engine model classification
1 P 70 F / P - H
Identify number
Fuel „F“ gasoline
Air cooling
Bore „mm“
Vertical power shaft
Single cylinder
7
Revision 12/2013
2
1
