VARISCO V Series - Adjusting the Axial Play

Page32
9.6 Adjusting the axial play
! The axial play is dependent on the viscosity and can be adjusted through various thicknesses of
the cover or the casing seal. Please see the table below for further information.
Class
Pump type
V25-2
V30-2
V50-3
V60-2
V70-2
V80-2
V85-2 V100-2
1
0.2 mm
0.2 mm 0.3 mm 0.5 mm
2
0.3 mm 0.5 mm 0.7 mm 0.7 mm
3
0.5 mm 0.7 mm - 1.0 mm
Pump type
Viscosity
Stainless steel
G
r
e
y
cast iron
Class 2 Class 1 up to 600 cSt and up to 180°C
Class 3 Class 2 from 600 to 6000 cSt and up to 180°C
Class 3 Class 3 over 6000 cSt and over 180°C
