Varytec ARC One - DMX Table with 17 Channels

20 / 23
11.2. DMX Table with 17 Channels
Ch Value Function
1 0 – 255 Tilt
2 0 – 255 Tilt Fine
3 0 – 255 Dimmer 0 – 100%
4 0 – 255 Red Dimmer 0 – 100%
5 0 – 255 Green Dimer 0 – 100%
6 0 – 255 Blue Dimmer 0 – 100%
7 0 – 255 White Dimmer 0 – 100%
8 0 – 255 Strobe effects
9 1 – 7
8 – 14
15 – 21
22 – 28
29 – 35
36 – 42
43 – 49
50 – 56
57 – 63
64 – 70
71 – 77
78 – 84
58 – 91
92 – 98
99 – 105
106 – 112
113 – 119
120 – 126
127 – 133
134 – 140
141 – 147
148 – 154
155 – 161
162 – 168
169 – 175
176 – 182
183 – 189
190 – 196
197 – 203
204 – 210
211 – 217
Tilt Stand Alone Program 1
Tilt Stand Alone Program 2
Tilt Stand Alone Program 3
Tilt Stand Alone Program 4
Tilt Stand Alone Program 5
Tilt Stand Alone Program 6
Tilt Stand Alone Program 7
Tilt Stand Alone Program 8
Tilt Stand Alone Program 9
LED only no Tilt Stand Alone Program 1
LED only no Tilt Stand Alone Program 2
LED only no Tilt Stand Alone Program 3
LED only no Tilt Stand Alone Program 4
LED only no Tilt Stand Alone Program 5
LED only no Tilt Stand Alone Program 6
LED only no Tilt Stand Alone Program 7
LED only no Tilt Stand Alone Program 8
LED only no Tilt Stand Alone Program 9
Tilt Stand Alone Sound Program 1
Tilt Stand Alone Sound Program 2
Tilt Stand Alone Sound Program 3
Tilt Stand Alone Sound Program 4
Tilt Stand Alone Sound Program 5
Tilt Stand Alone Sound Program 6
Tilt Stand Alone Sound Program 7
Tilt Stand Alone Sound Program 8
Tilt Stand Alone Sound Program 9
LED only no Tilt Stand Alone Sound Program 1
LED only no Tilt Stand Alone Sound Program 2
LED only no Tilt Stand Alone Sound Program 3
LED only no Tilt Stand Alone Sound Program 4
