Important: Damages caused by the disregard of this user manual are not subject to
warranty. The dealer will not accept liability for any resulting defects or
problems. Make sure the electrical connection is carried out by qualified
personnel. All electrical and mechanical connections have to be carried out
according to the European safety standards.
2. Technical Data
Power supply
100
-
240V
50
/60
Hz
Power consumption
60
W
Current
0.
26
A
Sound
to Light
Via
built in mic
DMX512
connection
3 Pin XLR
Weight
2,4
Kg
Measurements
274 x 265 x 109m
m
Maximum ambient temperatur
e
-
20
°
-
+40°
C
Maximum housing temperature
+20
°
-
+60°
C
Fuse
F1A, 250V
Channel
6
Number of LEDs
18
x 3W
single colours
LEDs
(6R, 6G, 6B)
4500Lux @1m
25
°
3. Operation
3.1. System menü
the system menu is built like described below this information. Generally you can leave menus
with ESC, until you reach the highest control line). With ENTER you can recall a function to set up
the according values, then you can change these values by using the UP/DOWN buttons. Always
confirm your set up by using ENTER. With ESC you can go back and leave this menu.
